Multi Jet Fusion 3D Printing Service PA12 GB Auto Parts Rapid
Prototype For Automotive Industry
HP MJF 3D Printing Service PA11 Rapid Prototype For Cultural
Creativity
--------------------------------------Technical
Datas-------------------------------------
| |
| Auto CAD, Soid vvorks, Pre/Engineer, Catia v5, UG, Mastercam |
| STEP, STP,IGS,STL,PRT,DWG,PDF,AI ,etc |
| |
| Up to customer's requirement |
Surface treatment | Polishing, Painting,Plating, Anodizing,Hard anodizing, Brushing,
Silk screen, Water Transfer,Laser engrave, Sandblasting, Gilding,
Powder coating, Pad printing etc. |
| Ra≦0.05-3.2, up to your requirement detail |
| ±0.01mm to ±0.05mm, up to your requirement detail |
| CMM, Projector, Caliper, height gauge, GO - NO GO FIXED GAUGES, pin
gauge etc. |
| Wood case, carton box, PE bag, foam, etc.
custom-made as customer's requirement |
| 3-5days depends on quantity, simple parts only 1 day |
| air or sea transportation by DHL, UPS, TNT, FedEx etc. |
| 4-7 working days by air, about 35 days by sea. |
-----------------------------------------Advantage-----------------------------------------
1. One-stop service: We can provide 3D scanning, 3D modeling, data
processing, reverse engineering, 3D printing, post-processing and
other services.
2. Comprehensive solution : According to the actual needs of
customers, formulate the most suitable comprehensive solution to
effectively save the cost for customers.
3. Data confidentiality system : With a strict internal
confidentiality system, we can sign confidentiality agreements
according to customer needs in order to ensure the information
security of customer creativity.
4. Strong delivery capabilities : We have 100+ industrial-grade 3D
printers and a technical service team of more than 100 people to
ensure that products are delivered on time.
5. Competitive prices : We can provide most competitive prices in
the market.
6. Quick Response : Your inquiry will be replied in 24 hours, sales
are more than 10 years of engineer background, react fast and give
strong support.
7. Quality Guarantee : Experienced engineers, precision production
machines, precision inspection equipment with experienced
inspectors and QC system to ensure quality.
8. Good Service : Good service runs throughout the whole process
from inquiry/quotation, sampling, production, inspection, packaging
to delivery and after sale.
9. Value-added services : A trusted partner who can help you
purchase a variety of other legal items, including a variety of
special products.
-----------------------------Introduction Of 3D
Printing------------------------------
| Technology | Recommend | Material |
DMLS 3d printing service | DMLS(DIRECT METAL LASER SINTERING): uses lasers to fuse powdered
metals into functional prototypes and end-use parts. | Titanium, Aluminium, Stainless Steel... |
| SLA 3d printing service | SLA(Stereo Lithography Apparatus): uses an ultraviolet (UV) laser
to turn light-sensitive resin (a liquid material that becomes hard
when ultraviolet light is shined on it) into solid 3D objects,
layer by layer.SLA is very good way to make the complex structure
and small parts with good tolerance and very good surface finish,
can be paint in different colors. | Resin (ABS-Like and Acrylic-like) |
| MJF 3d printing service | Multi Jet Fusion or MJF 3D printing technology is perfect for those
times when you are looking for lower porosity, short lead times and
unsurpassed surface quality. If you are manufacturing complex
end-use parts and have decided to produce it in a low
volume, then MJF can be the best option for you.
Part is made by HP printer, and has got very good strength, now it
is mostly in grey black color. | PA11, PA12, PA2200, PA12GB, PA66 |
| FDM 3d printing service | FDM(Fused Deposition Modeling): is the most cheap technique, that
diffuses a plastic wire into shape.
Very cheap and which is strong, but the surface is not so good,
rougher than SLA parts. FDM parts have to be print with support. | PLA(Polylactic Acid ), ABS(Acrylonitrile Butadiene Styrene),
RUBBER(TPE / TPU), PLA+Wood, Metal PLA / Metal ABS,Carbon Fiber
etc. |
| SLS 3d printing service | SLS(Selective Laser Sintering): can produce parts for strong
material like nylon (PA) and also fiber glass reinforced parts,
result is very strong part but process is made from powder.
Mainly with NYLON material and very strong, and surface is rough as
well, now it is mostly in grey white color. | Nylon and Nylon fiber glass, Metal powder, Ceramic powder |
--------------------------------------What we can
do-------------------------------------
| Material | Resin 9400 | Imported Resin 8000 | Transparent Resin | High Tenacity Resin | Yellow HTR | Grey HTR | Black Nylon PA12 |
| heat distortion temperature (0.46MPa) | 46 | 46 | 47 | 38-50 | 70 | 99.6 | 173 |
| Min Wall Thickness | 0.6mm | 0.6mm | 0.6mm | 0.6mm | 0.6mm | 0.6mm | 0.5mm |
| Min Hole Diameter | 1mm | 1mm | 1mm | 1mm | 1mm | 1mm | 1.2mm |
| Materal Hardness (Shore D) | 79 | 79 | 87 | 85 | 80 | 85 | 86 |
| Extension Strength (Tensile) | 47MPa | 47MPa | 50MPa | 38-56MPa | 48MPa | 40-44MPa | 50MPa |
| Extension Strength (Fracture) | 33-40MPa | 33-40MPa | 56MPa | 60MPa | 56MPa | 52MPa | 70MPa |
| Bending Strength | 67MPa | 67MPa | 84MPa | 69-74MPa | 68MPa | 64-69MPa | 75-80MPa |
| Bending Modulus(MPa) | 2178-2222 | 2178-2222 | 2490 | 2692-2775 | 2300 | 2900-3200 | 2800 |
| Printing Height | 0.1/0.05 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 |
| Printing Error Range | 3/1000 | 3/1000 | 3/1000 | 3/1000 | 3/1000 | 3/1000 | 2.5/1000 |
| Moisture Absorption | 4/1000 | 4/1000 | 4/1000 | 4/1000 | 4/1000 | 4/1000 | |
| Impact Strength | 23-29J/CM | 23-29J/CM | 25J/CM | 45-29J/CM | 33J/CM | 34.4J/CM | 2.7KJ/CM |
------------------------------------------Application---------------------------------------
| Cultural creativity | Cultural relic restoration and sand table making, design
decoration, craft gift customization, etc. |
| Automotive industry | Light housing, interior housing, furniture and brake calipers, etc. |
| Consumer products | Prototypes in various fields such as home furnishings and
accessories |
| Medical industry | Customized braces, surgical aids and rehabilitation equipment |
| Education | Enriching the display of education in the fields of medicine,
biology, archaeology, etc. |
| Electronic products | Electronic circuits, structural verification, product housing
prototypes |
| Industrial manufacturing | Industrial equipment parts, mold processing and repair, incomplete
parts processing and repair |
---------------------------------------------FAQ----------------------------------------------
Q : Are you a factory or trading company?
A : We are a factory, we have our own machinery and equipment and
our factory covers an area of 3000 square meters.
Q : How do I get a quote?
A : Send us inquiry, or send Email to suvaxie@gmail.com, we would
contact you ASAP.
Q : Can we get some samples before mass production?
A : Absolutely. Contact us and let us know your requirements.
Q : What shall we do if we don't have drawings?
A : Please send your sample to our factory, then we can copy and
provide you better solutions. If send us pictures or drafts with
dimensions(Length, Hight, Width), CAD or 3D file will be made for
you.
Q : How long will i get the sample?
A : Depends on your specific items, within 3-7 days generally.
Q : What is your production range?
A : We provide a wide range of materials, including Resin, ABS,
Plastic, Nylon, Carbon fiber nylon, Stainless Steel, Aluminium,
Copper, Silver, Titanium.
If you have any other questions, please feel free to contact us and
we are happy to reply.
------------------------------------------About
us------------------------------------------
Kuaima Sanwei is a rapid prototype and manufacturing expert with
over 7 years experience.
Guangdong Kuaima Sanwei is a leading integrated solution specialist
of 3D prototype model in China. We provide professional
customization prototype services and small batch production
services , which including 3D modeling and 3D printing, CNC machin,
Injection Molding, and post process such as plating, painting and
electroplating.
We also offer various surface finishing, including painting,
anodizing, sandblasting, black oxide, high polishing, nitride, heat
treatment, PVD coating, chrome plating, PC fumigation, UV varnish,
Carburizing and so on.
Wanna know the best competitive and most suitable solution for your
project? Talk to us!
